- Description
Model | ZP-51D | ZP-65D | ZP-83D | ZP-99D |
Dies No. | 51 | 65 | 83 | 99 |
Max. Pressure | Main pressure 150kn, pre-pressure 150kn | Main pressure 150kn, pre-pressure 150kn | Main pressure 150kn, pre-pressure 150kn | Main pressure 150kn, pre-pressure 150kn |
Max. Dia. of Tablet | 25mm | 16mm | 13mm | 10mm |
Max. Depth of Filling | 20mm | 18mm | 18mm | 18mm |
Rotary Speed | 10-80 r/min | 10-80 r/min | 10-80 r/min | 10-80 r/min |
Max. Production Capacity | 470000 pcs/h | 620000 pcs/h | 790000 pcs/h | 950000 pcs/h |
Max.Thickness of Tablet | 1-8mm | |||
Power | 11kw | |||
voltage | 380 220V/50Hz | |||
size | 1310*1305*2010 mm | |||
Weight | 5510kg |





Payment Methods
These payments of T/T, L/C, Paypal are accepted. If you have any problem with the payment, please leave a message to us.
Logistics
DHL, EMS and UPS, Fedex are our choices. If you prefer other reliable shipping company. Please leave a message to us.
Tracking Number
Tracking number will be informed within 2-3 work days after delivery goods. If you have any problem with it, please leave a message to us.
Feedback
Any comments, suggestions are accepted. We will be very grateful to your positive footprints left in our company. If you have any problem with our products, please leave a message to us.
Refund
Any damage or shortage of our goods when you receive your items. Please take some photos for a witness. We will deal with it in 24 hours. Frequently, we will send a new part of items for alternative and heavy-damage, Before refund is accepted, please leave a message to us.
Contact information:
Email- yk@yolimachine.com
Phone- +8615815351839
Wechat- h15815351839
Whatsapp +8615815351839
Skype+8615815351839
GZP series intelligent rotary tablet press provides new design principle, which makes standardization, modularity and series design come true. The characteristic of machine is high-precision, sub high-speed and automation.
It is the best choice for high output and large batch production
II. Features
Design of GMP
High quality all stainless steel construction
Special oil-proof and dust-proof sealing system
Reliable safety sealing system and dust-proof system
High visibility isolated door to prevent cross contamination
Easily remove and install parts for quick machine's maintenance
360°design for easy observation and cleaning
Model | GZP-17 | GZP-22 | GZP-26 |
Number of Station | 17 | 22 | 26 |
Single Sided | Single Sided | Single Sided | Single Sided |
Max. Revolution (RPM) -Empty Load | 77 | 77 | 77 |
Max. Revolution (RPM) Standard ( Round Tablet) |
65 | 65 | 70 |
Min. Revolution (RPM) | |||
Max. Output (tablets\h) | 78500 | 101600 | 120100 |
Capacity (tablets/h)--shaped tablet | 56000 | 72000 | 88000 |
Max. Tablet Diameter (mm) | 22 | 16 | 12 |
Max. Filling Depth (mm) | 16 | 16 | 16 |
Max. Tablet Thickness (mm) | 8 | 8 | 8 |
Max. Compression Force | 100 | 100 | 100 |
Max. Pre-compression Force (kN) | 16 | 16 | 16 |
Feed mechanism | Forced feeding | Forced feeding | Forced feeding |
Main Motor Power(kW) | 5.5 | 4 | 4 |
Power requirement | 380V, 50HZ, 3P | 380V, 50HZ, 3P | 380V, 50HZ, 3P |
Overall Dimension (mm) | 600 x700 x1800 | 600 x 700 x1800 | 600 x 700 x1800 |
Weight (Kg) 1200 1150 1150 | Weight (Kg) 1200 1150 1150 | Weight (Kg) 1200 1150 1150 | Weight (Kg) 1200 1150 1150 |
